Toroidal Soft Magnetic Amorphous Inductor Cores for Car Audio

Amorphous Cores for Car Audio Inductor:

Fe-based amorphous core applied in car audio inductor provides the good frequency property, AC/DC superposition characteristics and low core loss. And the wide permeability range from 120 µ to 1200 µ . It is a good choice for the inductor, choke and filters in high frequency and AC/DC superposition situation, and with better price than FeNiMo, FeNi and FeSiAl powder cores.

Features:

• High saturation flux density Bs, low Hc, Low loss.
• Excellent Anti DC bias property.
• High permeability of 120 to 1200µ, Less wire winding turns.

Magnetic Performance:

Item	Performance	Item	Performance
Saturate induction Bs(T)	1.56	Magnetostriction λs	27×10 -6
Curie temperature Tc（℃)	400	Density ρ（g/cm3）	7.18
Crystallization Tx（℃)	515	Resistivity δ（μΩ.cm）	130
Hardness（Hv）	960	Coercivity  Hc（A/m)	<4

Applications:

• Car audio choke coils
• PFC corrector inductors
• DMC fillers and smooth output filters
• DC/DC transformer filters

Specifications:

Part No.	Core Size	Finished Size	AL min.	N	Idc	Lv  (min).
	(mm)	(mm)	Idc=0	(Turns)	(A)	Idc=Rated
			(μH)			(μH)
SC-AOC07	6.5×9.8×4.5	5.1×11.2×5.9	0.12	50	0.3	150
SC-AOC08-1	8×12×4.5	6.3×13.8×6.5	0.1	50	1.5	160
SC-AOC08-2	8×12×4.5	6.3×13.8×6.5	0.19	38	1	100
SC-AOC09	8.5×15.3×5.0	7.4×16.8×6.3	0.21	36	1	240
SC-AOC10-1	10×16×8.0	8.3×18.2×10.3	0.13	40	2	150
SC-AOC10-2	10×16×8.0	8.3×18.2×10.3	0.21	46	2	300
SC-AOC10-3	10×16×8.0	8.3×18.2×10.3	0.62	27	1	300
SC-AOC10-A	10×18.5×5.0	8.0×20.8×6.8	0.26	35	2	230
SC-AOC10-B	10×18.5×5.0	8.0×20.8×6.8	0.35	43	1	500
SC-AOC11-1	11×18×8.0	8.8×19.8×9.7	0.55	21	2	180
SC-AOC11-2	11×18×8.0	8.8×19.8×9.7	0.78	24	1	300
SC-AOC11-A	11×18×10	8.8×19.8×11.9	0.2	50	1	400
SC-AOC11-B	11×18×10	8.8×19.8×11.9	0.63	26	2	280
SC-AOC11-C	11×18×10	8.8×19.8×11.9	0.85	23	1	400
SC-AOC12-1	12×20×8.0	10.6×21.8×10	0.3	27	2	190
SC-AOC12-2	12×20×8.0	10.6×21.8×10	0.56	25	1	350
SC-AOC12-A	12×20×10	10.6×21.8×12	0.84	21	1.5	250
