High Rectangular Ratio Nanocrystalline Cores for Magnetic Amplifiers (Mag Amp)
Magnetic amplifiers, also known as mag-amps, are devices that use magnetic cores to amplify electrical signals. Compared with Permalloy, ferrite or amorphous alloy, Nanocrystalline cores are often used in magnetic amplifiers due to their unique magnetic properties including high permeability, high rectangular ratio and ideal high temperature stability.
- Trade Mark: SHOUCORE
- Cores Size: Standard or Customized Dimensions
- Certificates: ISO 9001:2015, RoHS, REACH
- Payment Terms: T/T or L/C
- Delivery time: Samples: 3~5 days; Batches: 7~30 days
Iron-based Nanocrystalline mag amp Cores :
Magnetic amplifiers, also known as mag-amps, are devices that use magnetic cores to amplify electrical signals. Compared with Permalloy, ferrite or amorphous alloy, Nanocrystalline cores are often used in magnetic amplifiers due to their unique magnetic properties including high permeability, high rectangular ratio and ideal high temperature stability, which can provide unmatched output regulation and achieve higher working efficiency in swithing power supplies.
Features:
1) High permeability
2) Low coercivity
3) High rectangular ratio
4) Small recovery current
5) High temperature stability
6) Less core loss
Applications:
- Switch mode power supply (SMPS)
- Communication system
- Automatic control system
- Industrial power supply
Specifications:
| Part No. | Core dimensions(mm) | Finished dimensions(mm) | Le(cm) | Ae(cm2) | ||||
| ID | OD | H | ID | OD | H | |||
| SC-MA08 | 8 | 12 | 4.5 | 6.2 | 14.7 | 6.8 | 3.14 | 0.07 |
| SC-MA09-A | 8.4 | 12 | 3.2 | 5.9 | 14.7 | 5.4 | 3.2 | 0.045 |
| SC-MA09-B | 8.7 | 11.8 | 4.2 | 6.8 | 13.9 | 6.0 | 3.22 | 0.051 |
| SC-MA10 | 10 | 15 | 4.5 | 8 | 17 | 7.1 | 3.93 | 0.088 |
| SC-MA15 | 15 | 19 | 5 | 13 | 21 | 6.6 | 5.34 | 0.078 |
